AURORA WB

Plastic industrial LED light fitting with high chemical resistance, suitable for rooms with high ceilings, with diffuser made of transparent acrylate.

Closed non-dismountable light fitting intended for chemically challenging or agricultural premises with incidence of vapors like ammonia, lye, alkaline compounds and hot water (hydrolysis). Thanks to the Narrow Beam optics, it is suitable for inside spaces with high ceilings, intended for suspension height from 8 to 12 m, e.g. inside walls and corridors of high agricultural and industrial buildings, rack aisles in production and storage spaces, farms, stables and laboratories without explosion hazard. The structural design of the light fitting (IP69) allows even placement in food-processing industry – HACCP.

The light fitting resists dust, humidity and washing with spouting water up to 80 °C. The body made of ABS material and the diffuser made of AC material have high chemical resistance.

Easy, fast and maximally efficient mounting is achieved when using the cables with connectors delivered by us.

Sports facilities Industry Infrastructures Agricultural Interior lighting

Description

Features:

  • From 16W to 45W
  • IP66 / IP69and IK10
  • Maximum ambient temperature: ta = 50 °C
  • Lifetime: 50,000 hours / L90B10
  • Standard model – CRI > 80: 4000 K
  • Body: grey PC (high mechanical resistance, UV stability)
  • Certification: ESČ, ENEC, CB, HACCP, CE
  • The watt and lumen values can, in accordance with valid standards, vary by ± 7,5 %

Technical information:

  • Diffuser: transparent PC with Fresnel lenses, Wide Beam (high mechanical resistance, UV stability)
  • Connectors with 3, 5 or 7 poles, wire section 1.5 or 2.5 mm2
  • Interconnection cable with two connectors for mutual spacing between light fittings of 0 m, 1 m, 3 m or for requested spacing
  • Cable with one connector for connection of the light fitting to the voltage source in a distance of 1 m, 3 m or in a requested length
  • Ventilation membrane in the body against condensation
  • Installation options: attachment with the use of side hangers to the wall/ Directly to a ceiling or a wall with the use of screws and stainless brackets/ Suspension with the use of stainless hooks

Areas of application:

  • Industrial: Factories/ Warehouses/ Food industry
  • Indoor: Commercial lighting/ Culture and education/ Staircases and corridors/ Health care
  • Infrastructures: Stations and terminals/ Garages
  • Agricultural: Farms and stables/ Mills and granaries
  • Sports grounds: Indoor sports grounds
Type Ta. Max Luminous flux light fitting (lm) Power (W) Efficacy (lm/W) Net weight (kg) Luminaire length (mm)
AURORA WB 2600/840 50 2240 16 140 1.5 1175
AURORA WB 3200/840 50 2710 20 136 1.5 1175
AURORA WB 4400/840 45 3780 27 140 1.5 1175
AURORA WB 6400/840 45 5450 38 143 1.5 1175
AURORA WB 3250/840 50 2820 20 141 1.8 1455
AURORA WB 4000/840 50 3380 24 141 1.8 1455
AURORA WB 5500/840 45 4720 33 143 1.8 1455
AURORA WB 8000/840 45 6730 45 150 1.8 1455
